Overview
Comant’s four through hole mount blade style VHF communication antenna with BNC port. Suitable for either top or bottom mounting with both light and heavy fixed wing single engine / multi-engine and business jet aircraft.
Antennas, Avionics, Avionics & Instruments, Comant
CI-268-5 Comant VHF Comm Blade
Part #: CI-268-5
CI2685
R$10,157.51
| Peso | 0.57 lbs |
|---|---|
| Brands |
Specifications
- Electrical
- Frequency: 118-137 MHz
- VSWR: 2.9:1 Max
- Polarization: Vertical
- Radiation Pattern: Omnidirectional
- Impedance RF: 50 Ohms
- Power RF: 50 Watts
- Harmonic Rejection: 80 dB Typical
- Mechanical
- Weight: 1.25 lb
- Height: 14.1 in
- Material: Molded Glass Filled Nylon
- Finish: Glossy White
- Connector: BNC (female)
- Environmental
- Temperature: -55 to +85 Celsius
- Altitude: 35,000 ft.
- Federal Specifications
- FAA TSO C37d, C38d
- RTCA Environmental DO-160D
